OEM YZ30S08-1207B Low Frequency 0.8VA PCB Mounting Step Down Transformer 50HZ Suppliers, Manufacturers

Primary Voltage： 115V
Part Number	Primary (V)	Secondary (V)	Secondary (mA)	No-Load Voltage (V)	Schematic No.	Ambient Temperature
Y230US08-0607B	115	6	133.3	8.0	1	ta 70/B
YZ30US08-0727B	115	7.2	111.1	9.6	1	ta 70/B
YZ30US08-0907B	115	9	88.9	12.0	1	ta 70/B
YZ30US08-1007B	115	10	80.0	13.3	1	ta 70/B
YZ30US08-1207B	115	12	66.7	16.0	1	ta 70/B
YZ30US08-1507B	115	15	53.3	20.0	1	ta 70/B
YZ30US08-1807B	115	18	44.4	24.0	1	ta 70/B
YZ30US08-2407B	115	24	33.3	32.0	1	ta 70/B
YZ30UD08-0607B	115	2x6	2x66.7	2x8.0	2	ta 70/B
YZ30UD08-0727B	115	2x7.2	2x55.6	2x9.6	2	ta 70/B
YZ30UD08-0907B	115	2x9	2x44.4	2x12.0	2	ta 70/B
YZ30UD08-1007B	115	2x10	2x40.0	2x13.3	2	ta 70/B
YZ30UD08-1207B	115	2x12	2x33.3	2x16.0	2	ta 70/B
YZ30UD08-1507B	115	2x15	2x26.7	2x20.0	2	ta 70/B
YZ30UD08-1807B	115	2x18	2x22.2	2x24.0	2	ta 70/B
YZ30UD08-2407B	115	2x24	2x16.7	2x32.0	2	ta 70/B

Primary Voltage： 115VX2
Part Number	Primary (V)	Secondary (V)	Secondary (mA)	No-Load Voltage (V)	Schematic No.	Ambient Temperature
YZ30XD08-0607B	2X115	2x6	2X66.7	2x8.0	3	ta 70/B
YZ30XD08-0907B	2X115	2x9	2X44.4	2x12.0	3	ta 70/B
YZ30XD08-1207B	2X115	2x12	2X33.3	2x16.0	3	ta 70/B
YZ30XD08-1507B	2X115	2x15	2X26.7	2x20.0	3	ta 70/B
YZ30XD08-1807B	2X115	2x18	2X22.2	2x24.0	3	ta 70/B
YZ30XD08-2407B	2X115	2x24	2X16.7	2x32.0	3	ta 70/B

Primary Voltage：230V
Part Number	Primary (V)	Secondary (V)	Secondary (mA)	No-Load Voltage (V)	Schematic No.	Ambient Temperature
YZ30S08-0607B	230	6	133.3	8.0	1	ta 70/B
YZ30S08-0727B	230	7.2	111.1	9.6	1	ta 70/B
YZ30S08-0907B	230	9	88.9	12.0	1	ta 70/B
YZ30S08-1007B	230	10	80.0	13.3	1	ta 70/B
YZ30S08-1207B	230	12	66.7	16.0	1	ta 70/B
YZ30S08-1507B	230	15	53.3	20.0	1	ta 70/B
YZ30S08-1807B	230	18	44.4	24.0	1	ta 70/B
YZ30S08-2407B	230	24	33.3	32.0	1	ta 70/B
YZ30D08-0607B	230	2x6	2x66.7	2x8.0	2	ta 70/B
YZ30D08-0727B	230	2x7.2	2x55.6	2x9.6	2	ta 70/B
YZ30D08-0907B	230	2x9	2x44.4	2x12.0	2	ta 70/B
Y230D08-1007B	230	2x10	2x40.0	2x13.3	2	ta 70/B
YZ30D08-1207B	230	2x12	2x33.3	2x16.0	2	ta 70/B
YZ30D08-1507B	230	2x15	2x26.7	2x20.0	2	ta 70/B
YZ30D08-1807B	230	2x18	2x22.2	2x24.0	2	ta 70/B
YZ30D08-2407B	230	2x24	2x16.7	2x32.0	2	ta 70/B

Product description:

Introducing the Low Frequency zero.8VA PCB Mounting Step Down Transformer 50HZ, a reliable and efficient element designed for various packages. Here are the key parameters of this product:

**Applications:**

This transformer is well-appropriate for diverse programs, in particular inside the fields of:

- **Switching Power Supply**

- **Intelligent Controller**

- **Central Air-Conditioning Thermostat**

**Features:**

- The inherently brief-circuit-evidence design guarantees safety and reliability in operation.

- Utilizes self-extinguishing materials for enhanced hearth safety.

- Potted beneath vacuum for extended safety and sturdiness.

- Suitable to be used in switching energy deliver structures, sensible controllers, and primary air-conditioning thermostats.

- Versatile enter voltage alternatives make it adaptable to distinctive strength supply scenarios.

**Performance:**

With its Class B insulation and dielectric electricity of four,500Vrms, this transformer demonstrates sturdy performance even in stressful conditions. The 0.8VA electricity score makes it appropriate for numerous low-frequency programs.

**Weight and Compact Design:**

Weighing best 70g, this transformer is lightweight and compact, making it smooth to integrate into your digital structures without adding pointless bulk.

In summary, the Low Frequency zero.8VA PCB Mounting Step Down Transformer 50HZ is a flexible and high-performing factor designed to meet the electricity deliver wishes of switching structures, clever controllers, and primary air-conditioning thermostats. Its robust layout and key functions make it a reliable choice for your digital packages.
